Working deflection PCB 19v2000

Bump


The keys are ditterent on the connectors. What do you have to change?

IIRC I had to cut or bend over one pin (I think it was pin 4 or 5) on the 802 deflection board to fit the 19v2000 wire harness (key) . I think that is it.

Maybe someone else can confirm?

I may be wrong but I think the "19v2000" and the "802" deflection boards should be interchangable.

There's at least 3 common 'issues' of the G05-802 deflection board, and the 19v2000 is only a copy of one of them...

I can't remember offhand which are interchangable, but there should be a doc floating around that I wrote up years ago saying how to mod the board to make them interchangeable...

Deflection

it is an issue 5. I moved pin 4 and 5 on p500 and put the 802 def pcb in. Now I have a spot killer. with brightness turned all the way up, I still dont have a dot in the center of the screen.
