Help identify these PCB's - Gottlieb and SNK

jehuie

Well-known member

Donor 2011
Joined
Sep 8, 2007
Messages
10,947
Reaction score
1,672
Location
Martinez, California
So I have two Gottlieb boards that look just alike but have different numbers. One says C-22248-1 and the other says C-22248-3.

And Then I have a SNK 2-board set with one board labeled 84602-02A and the other is 84602-01A-4 and looks like it might be JAMMA??

Here's pics:

attachment.php


attachment.php


attachment.php


Attachments

  • Unknown pcbs 010 (Medium).JPG
    Unknown pcbs 010 (Medium).JPG
    96.9 KB · Views: 161
  • Unknown pcbs 009 (Medium).JPG
    Unknown pcbs 009 (Medium).JPG
    98 KB · Views: 161
  • Unknown pcbs 008 (Medium).jpg
    Unknown pcbs 008 (Medium).jpg
    85 KB · Views: 162
So I have two Gottlieb boards that look just alike but have different numbers.

On the Gottlieb boards, what are the numbers on the ROMs (the GV1xx)? That will tell you what game it is. For example, GV103 is Q*bert, GV100 is Reactor, GV102 is Mad Planets, etc.. I'm guessing yours is GV109, which is Mach 3.

On the Gottlieb boards, what are the numbers on the ROMs (the GV1xx)? That will tell you what game it is. For example, GV103 is Q*bert, GV100 is Reactor, GV102 is Mad Planets, etc.. I'm guessing yours is GV109, which is Mach 3.

Both say GV103....so two Q-bert boards, apparently. Interesting. Thanks for the info!

comparing that visible Q*bert board to mine it looks like it's complete at least. no audio or PS boards to go with them?

comparing that visible Q*bert board to mine it looks like it's complete at least. no audio or PS boards to go with them?

I have a ton of other boards and stuff but haven't noticed and audio or PS board. Not sure what they look like though and I still have many that I've not yet identified. If I can find a link to a pic I'll look around a bit and let you know.

I've had pretty good luck with the boards in this load working. Maybe 80% or so seem to work with no problems out of the few that I've been able to test. Those are pretty much all JAMMA boards though.

i can see that top Q*bert still has the battery. might want to take that thing off ASAP. i pulled mine when i got my cab last week and the thing had just started to leak; only a tiny bit of corrosion to stop.

attached is a picture of the power supply board (on the left with the two tall blue caps,) and the audio board on the right. i have a very early Q*bert so mine lacks the filter board of the later units.

if there isn't any other identifying information, the ROMs on the audio board should also have the game ID number (like GV-103) printed on them. i'm not sure on variants of the PS board; the link for Mike's Arcade's page might give you more info if you do find one.


Attachments

  • qbert ps and audio pcbs.jpg
    qbert ps and audio pcbs.jpg
    98 KB · Views: 16
Last edited:
Thanks for the pics. I did find a PS board but haven't really dug through yet much. There may be a sound board in here too.

Hey, I found a sound board too so now I have a full set. I'd like to put them up for sale but I don't know where I'll find a box this big.
