I am nearly finished putting the Amplifone deflection PCB harnesses together. I'm making 30 to start with and will likely build more if there's a demand for it.
These harnesses are made using new 20 gauge wire, with the 15 pin connector on one end, same as the harness on an original board. Wire colors, ties, and lengths matched to my Quantum deflection board shown below. The ONLY difference in wire length is that I extended the two purple wires to match the yellow, white, white/brn stripe, and grey wires. This is so that you can terminate those with a connector for the repro deflection PCB by Dezbaz, if you wish. I imagine some will just solder directly to the PCB (I plan to), so I didn't include those connectors. I did strip the PCB ends of the wire. Also, the twisted pairs are attached with wire ties about 1" from the ends. You can clip those off after attaching the board if you want.
I'm basing the price on price of materials, time, and what some of the repro control panel harnesses (similar wire/crimp count/parts cost) have sold for on KLOV.
The cost is $12.50/ea harness and $5.50 for shipping, which is USPS Priority with tracking # - $18/shipped for 1. I think I can ship 5 for same shipping cost, as I'm using flat rate boxes, so 2 for $30.50, 3 for $43, etc.. These will start shipping next week, unless I have demand past the 30, then I will let you know the status and wait time.
